Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Rhythm Float 34
-
Groupset XT, SLX -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano BT-E8010 -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 34 Float Rhythm, Boost
Rear Shock
FOX Float DPS Performance, Trunnion mount, 185mm x 50mm
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow+
Front Derailleur
N/A
Shift Levers
Shimano SLX, 11-speed
Cassette
Shimano SLX, 11-42 tooth, 11-speed
Crank
Shimano FC-E8000
Chain
Shimano CN-HG601
Chain Guide
N/A
Pedals
MTB Alu Flatpedal Reflex
Wheels
Front Hub
Shimano Deore, Boost front and rear
Rear Hub
Shimano Deore, Boost front and rear
Rims
Sun Ringle Duroc TR40
Tires
Front: Schwalbe Magic Mary Evolution, Addix Soft compound, Apex reinforced sidewall, tubeless easy, foldable, Rear: Schwalbe Nobby Nic Evolution, Addix Speedgrip compound, Apex reinforced sidewall, tubeless easy, foldable
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Cockpit
Stem
Oxygen E-Scorpo, 50mm, 31.8mm clamp, 6° angle
Handlebar
Oxygen E-Scorpo, 760mm width, 31.8mm diameter, 25mm rise, 9° sweep
Headset
Stevens MTB, IS42/IS52
Seat
Saddle
Oxygen Roccia
Seatpost
KS LEV-SI, 100mm, 125mm, 150mm drop options
Motor & Battery
Motor
Shimano E-8000
Battery
Shimano BT-E8010
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.415 mm | 1.36 mm | 1.321 mm | 1.301 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Stack | 604 mm | 608 mm | 617 mm | 627 mm |
| Reach | 427 mm | 447 mm | 467 mm | 482 mm |
| Top Tube Length | 554 mm | 574 mm | 595 mm | 612 mm |
| Seat Tube Angle | 76.9 ° | 76.9 ° | 76.9 ° | 76.9 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 490 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1162 mm | 1183 mm | 1207 mm | 1226 mm |
| Bottom Bracket Drop | 8 mm | 8 mm | 8 mm | 8 mm |
| Standover Height | 719 mm | 732 mm | 744 mm | 755 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
E-Whaka+ belongs to the Stevens E E Whaka model. There are 3 e-bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Trail e-bikes average weight
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 21.9 kg (48.28 lbs), the E-Whaka+ model is a bit lighter than average. In other words, this model is 8.22% lighter than the average Trail e-bike.
Overview of components
Fork
This e-bike has the Fox Rhythm Float 34 fork installed. The fork’s travel is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this e-bike is FOX Float DPS Performance, with a travel distance of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The E-Whaka+ 2018 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Whaka+ has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
A dropper post is included with the E-Whaka+. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
