Stevens San Remo 2023
2023 Road
Estimate price |
1,433$
Weight | 9.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 TB, O.L.D.: 130 mm, Brake: rim, BB: BSA 68 mm, Front derailleur mount: clamp, Cable routing: internal
Suspension Fork
STEVENS Carbon Pro-Blade, Tapered Steerer 1 1/8" - 1 1/4", O.L.D.: 100 mm, Brake: rim
Drivetrain
Rear Derailleur
Shimano Tiagra, RD-4700-GS, 10-speed, Total capacity: 41 T
Front Derailleur
Shimano Tiagra, FD-4700-BM, 2-speed
Shift Levers
Shimano Tiagra, ST-4700, 2-speed
Cassette
Shimano CS-HG500, 10-speed, Combination: 11-12-14-16-18-20-22-25-28-32 T
Crank
FSA CK-400, 50-34 T
Bottom Bracket
BSA, 68mm, threaded
Chain
Shimano CN-HG54
Wheels
Front Hub
Shimano Tiagra, HB-RS400, Axle: QR9x100
Rear Hub
Shimano Tiagra, FH-RS400, Axle: QR10x130 mm
Rims
Oxygen RM-R17, ETRTO: 17 x 622
Tires
Continental Grand Sport Race SL, Tire size: 25-622, Foldable, Pure-Grip compound, NyTech breaker
Brakes
Brakes
Shimano Tiagra, BR-4700, V-Brake
Cockpit
Stem
Oxygen Driver, Handlebar clamp: 31.8 mm, Angle: -6°
Handlebar
Oxygen Scorpo Aero, Drop: 130 mm, Reach: 80 mm, Clamp: 31.8 mm
Headset
STEVENS Race Taper 1 1/8"-1 1/4", Upper bearing cup: IS42/28.6, Lower bearing cup: IS47/33
Seat
Saddle
Oxygen Cyrius
Seatpost
Oxygen Driver, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 47cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.4 mm | 1.43 mm | 1.42 mm | 1.42 mm | 1.4 mm | 1.44 mm | 1.48 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 573 mm | 576 mm | 574 mm | 581 mm | 584 mm | 596 mm | 608 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72 mm | 72 mm | 65 mm | 60 mm | 56 mm | 53 mm | 52 mm | 54 mm |
| Stack | 504 mm | 518 mm | 531 mm | 544 mm | 551 mm | 561 mm | 586 mm | 605 mm |
| Reach | 371 mm | 369 mm | 371 mm | 384 mm | 389 mm | 402 mm | 406 mm | 409 mm |
| Top Tube Length | 496 mm | 507 mm | 518 mm | 539 mm | 546 mm | 562 mm | 574 mm | 582 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74.5 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 402 mm | 432 mm | 461 mm | 481 mm | 504 mm | 510 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 105 mm | 120 mm | 130 mm | 140 mm | 145 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 975 mm | 978 mm | 976 mm | 983 mm | 986 mm | 998 mm | 1010 mm | 1017 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 692 mm | 714 mm | 718 mm | 753 mm | 768 mm | 778 mm | 805 mm | 825 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
San Remo is part of the Stevens San model. 2 bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Stevens San Remo price was 1323$. In conclusion, this bike price is 153.21% lower than the price of the average Race bike.
Race bikes average weight
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 9.3 kg (20.5 lbs), Stevens bike is much heavier than average. To sum up, it’s 36.36% heavier than the average weight of Race bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
San Remo components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the San Remo bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The San Remo has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
