Stevens Strada 1000 2025
2025 Road
Estimate price |
2,442$
Weight | 9.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 TB, O.L.D.: 142 mm, Brake: Flatmount disc 6", BB: Pressfit BB86, Front derailleur mount: clamp, Cable routing: internal (shifting)/external (brake), Fender + rack mounts
Suspension Fork
STEVENS Full Carbon SL, Tapered Steerer 1 1/8" - 1 1/2", O.L.D.: 100 mm, Brake: flatmount disc
Drivetrain
Rear Derailleur
Shimano CUES U8000 Shadow+, RD-U8020-SGS, 11-speed, Total capacity: 48 T
Front Derailleur
Shimano CUES U8000, FD-U8010-LM3, 2-speed
Shift Levers
Shimano CUES U8000, SL-U8000-IL, I-SPEC II, 2-speed
Cassette
Shimano CS-LG700-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-34-39-45 T
Crank
Shimano CUES U8000, Shimano FC-U8000-2, 46-32 T, Hollowtech II
Bottom Bracket
BB86/BB92, press-fit
Chain
Shimano CN-LG500, LINKGLIDE
Pedals
ATB Pro Reflex
Wheels
Rims
DT Swiss E 1800 Spline | Golden Grey: P 1800 Spline, Achse: QR12x100 mm
Tires
Continental Grand Prix Urban, Tire size: 35-622, Foldable, Black-Chili compound, PolyX Breaker
Brakes
Brakes
Shimano BR-RS405, Hydraulic disc brake
Brake Levers
Shimano BL-RS600
Cockpit
Stem
Oxygen Scorpo, Handlebar clamp: 31.8 mm, Angle: 6°
Handlebar
Oxygen Scorpo, Width: 600 mm, Backsweep: 9°, Rise: 0 mm, Clamp: 31.8 mm
Headset
STEVENS Race Taper 1 1/8"-1 1/2", Upper bearing cup: IS42/28.6, Lower bearing cup: IS52/40
Seat
Saddle
Selle Royal Vivo Ergo Sport
Seatpost
Oxygen Scorpo, Length: 320 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.393 mm | 1.429 mm | 1.436 mm | 1.445 mm | 1.466 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 614 mm | 624 mm | 635 mm | 656 mm | 680 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 77 mm | 71 mm | 64 mm | 65 mm | 63 mm |
| Stack | 542 mm | 570 mm | 593 mm | 617 mm | 645 mm |
| Reach | 389 mm | 399 mm | 413 mm | 427 mm | 440 mm |
| Top Tube Length | 550 mm | 579 mm | 600 mm | 621 mm | 644 mm |
| Seat Tube Angle | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 170 mm | 195 mm | 225 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1036 mm | 1046 mm | 1057 mm | 1078 mm | 1102 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 781 mm | 807 mm | 833 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
