Stevens Team RC 24” 2025
2025 Youth
Estimate price |
732$
Weight | 12.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 DB, O.L.D.: 135 mm, Brake: IS disc, BB: BSA 73 mm, Front derailleur mount: clamp, Cable routing: external, Rack mounts
Suspension Fork
SR Suntour XCT JR-L, Travel: 80 mm, Coil spring, Steerer 1 1/8", O.L.D.: 100 mm, Brake: postmount disc 6"
Drivetrain
Rear Derailleur
Shimano Acera, RD-M3020-8, 7/8-speed, Total capacity: 40 T
Front Derailleur
Shimano Altus, FD-M315-TS, 2-speed
Shift Levers
Shimano SL-M315, 2-speed
Cassette
Shimano CS-HG200-8, 8-speed, Combination: 12-14-16-18-21-24-28-32 T
Crank
Oxygen Aluminium Forged, 36-22 T, BB type: BSA 73 mm / Square Taper (axle length: 122 mm), Chainguard
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano HG-40
Pedals
ATB Pro Reflex
Wheels
Front Hub
Shimano HB-TX505, Axle: QR9x100 mm
Rear Hub
Shimano FH-TX505-8, Axle: QR10x135 mm
Rims
Oxygen RM-M19, ETRTO: 19 x 507
Tires
Schwalbe Smart Sam Active-Line, Tire size: 54-507, SBC compound, KevlarGuard
Brakes
Brakes
CLARKS M2, Hydraulic disc brake
Brake Levers
CLARKS M2, Grip-width adjustment
Cockpit
Stem
Oxygen Driver, Handlebar clamp: 31.8 mm, Angle: 6°
Handlebar
Oxygen Scorpo, Width: 640 mm, Backsweep: 9°, Rise: 15 mm, Clamp: 31.8 mm
Headset
STEVENS MTB 1 1/8", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30
Seat
Saddle
Oxygen Raceline
Seatpost
Oxygen Driver, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12.5" |
|---|---|
| Stack Reach Ratio | 1.488 mm |
| Bottom Bracket Height | 257 mm |
| Front Center | 568 mm |
| Rake | 40 mm |
| Stack | 512 mm |
| Reach | 344 mm |
| Top Tube Length | 491 mm |
| Seat Tube Angle | 74 ° |
| Seat Tube Length | 274 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 405 mm |
| Wheelbase | 969 mm |
| Bottom Bracket Drop | 45 mm |
| Standover Height | 629 mm |
| Wheels | 24" |
