Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Pinion -
Suspension Rigid -
Motor 750W 40Nm hub-drive -
Battery BQ655 48 V 655 Wh 120 km -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Frame size Sport: M <178 cm|L 175 - 188 cm
Suspension Fork
Aluminum Frame size Sport: M <178 cm|L 175 - 188 cm
Drivetrain
Shift Levers
Pinion C1.6 (295%)
Crank
Pinion Forged-175
Bottom Bracket
Pinion, press-fit
Wheels
Rims
Stromer 27.5 x 30
Tires
Pirelli Angel GT Urban | 57-584
Brakes
Brakes
Stromer HD922 by Tektro ABS at front: - No. of pistons at front | rear: 2 | 2 Brake disk at front | rear: 203 mm | 203 mm
Cockpit
Stem
Satori Python Stem 90 mm (SP Connect+ ready) Stem cell phone bracket: yes
Handlebar
Sweep Handlebar (rise 0 mm | Back Sweep 15°)
Grips
Ergon GA30 Single Twist Shift black
Seat
Saddle
Ergon ST10
Motor & Battery
Motor
CYRO Drive 3 Output in watts 750 W Torque in Nm 40 Nm
Battery
BQ655 48 V 655 Wh 120 km
Charger
Stromer CR246 246 W Max charging time : 4 h 15 min
