Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 50mm -
Fork RST VOLANT
-
Suspension Hardtail -
Motor Bosch 600W 75Nm mid-drive -
Battery BOSCH PowerTube, 625Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 161cm
MD
159cm - 171cm
LG
169cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6, Touring Geometry, Smooth Welding, Bosch system ready, integrated battery, Inner Cable Routing
Suspension Fork
RST Volant, 1-1/8", QR Type, 50mm travel
Drivetrain
Shift Levers
Enviolo Trekking 380 stepless
Cassette
Gates CARBON DRIVE CDX, 24T
Crank
ONE Sport, Alloy
Bottom Bracket
Bosch, press-fit
Chain
Gates CARBON DRIVE CDX
Pedals
Marwi SP-828
Wheels
Front Hub
ONE, KTMD7F, 36H, QR Type, 6-Bolts
Rear Hub
Enviolo Trekking, 36H, 6-Bolts
Rims
STARS J19DC, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
SCALATO MONDANO, 50-622, Reflective Tape
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 31.8mm, Adjustable
Handlebar
ONE Alloy, 38mm rise, 31.8mm
Headset
ONE PT-1866A-078-2 1-1/8“, ID52, Integrated
Seat
Saddle
Selle Royal Explora
Seatpost
ONE, Alloy, Suspension, 30.9mm
Motor & Battery
Motor
BOSCH Performance Line, 75Nm
Battery
BOSCH PowerTube, 625Wh
Charger
BOSCH 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.549 mm | 1.577 mm | 1.608 mm | 1.638 mm |
| Front Center | 649 mm | 655 mm | 661 mm | 667 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 86 mm | 80 mm | 76 mm | 71 mm |
| Stack | 604 mm | 626 mm | 648 mm | 670 mm |
| Reach | 390 mm | 397 mm | 403 mm | 409 mm |
| Top Tube Length | 580 mm | 600 mm | 620 mm | 640 mm |
| Seat Tube Angle | 72.5 ° | 72 ° | 71.5 ° | 71 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 69 ° | 69.8 ° | 70.5 ° | 71.2 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm | 200 mm |
| Chainstay Length | 485 mm | 485 mm | 485 mm | 485 mm |
| Wheelbase | 1127 mm | 1133 mm | 1139 mm | 1145 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 159 cm | 169 cm | 179 cm |
| Rider Max Height | 161 cm | 171 cm | 181 cm | 190 cm |
