Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 600W 75Nm mid-drive -
Battery BOSCH PowerTube, 625Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SU-EXC-W, Alu 6061 T6, Sport eMTB Geometry, Smooth Welding, Bosch system Powertube 625Wh battery ready, Inner Cable Routing
Suspension Fork
SR Suntour XCR32, Tapered, 15x110mm axle, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M4120, Shadow Design
Shift Levers
SHIMANO DEORE SL-M5100-R, RAPIDFIRE Plus, 11-speed
Cassette
SHIMANO DEORE CS-M5100, 11-speed, 11-42T
Crank
ONE Sport, Alloy
Bottom Bracket
Bosch, press-fit
Chain
KMC e11T
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CL, 15x110mm, THRU Type AXLE
Rear Hub
SHIMANO FH-MT400-B, 32H, CL, 12x148mm, THRU Type AXLE
Rims
STARS J30D, Disc, 32H
Spokes
SAPIM Galvanized Black
Tires
Schwalbe Hurricane Performance, 29x2.25, ADDIX
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE ICR, Alloy, 31.8mm, Adjustable
Handlebar
ONE Alloy, 25mm rise, 31.8mm
Headset
ACROS AZF-604, ZS56/28.6 - ZS56/40, BlockLock 120°
Seat
Saddle
Selle Royal Vivo
Seatpost
ONE Sport, Alloy, 30,9mm
Motor & Battery
Motor
BOSCH Performance Line, 75Nm
Battery
BOSCH PowerTube, 625Wh
Charger
BOSCH 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.683 mm | 1.634 mm |
| Bottom Bracket Height | 314 mm | 314 mm |
| Front Center | 682 mm | 703 mm |
| Rake | 46 mm | 46 mm |
| Trail | 109 mm | 109 mm |
| Stack | 643 mm | 652 mm |
| Reach | 382 mm | 399 mm |
| Top Tube Length | 570 mm | 590 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° |
| Seat Tube Length | 381 mm | 457 mm |
| Head Tube Angle | 67 ° | 67 ° |
| Head Tube Length | 130 mm | 140 mm |
| Chainstay Length | 500 mm | 500 mm |
| Wheelbase | 1176 mm | 1197 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm |
| Rider Max Height | 171 cm | 180 cm |
