Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 140mm -
Fork RST BLADE
-
Groupset Deore -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery BOSCH PowerTube, 500Wh -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SUE03-CXBES3, Alu X6 Ultralite MTB Trail, Advanced e-MTB Geometry, Travel 160/140 mm, BOSCH CX Performance 5G ready, Integrated battery up to 750Wh, 3D alloy one pice link, Alloy swingarm, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
RST Blade, 1.5", 15x110mm axle, 140mm travel
Rear Shock
RockShox Deluxe Select R, size 230x57.5mm
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5100, Shadow Plus Design
Shift Levers
SHIMANO DEORE SL-M5100-IR, RAPIDFIRE Plus, 11-speed
Cassette
SHIMANO DEORE CS-M5100, 11-speed, 11-51T
Crank
ONE Race, Alloy
Bottom Bracket
Bosch, press-fit
Chain
KMC e11T
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CL, 15x110mm, THRU Type AXLE
Rear Hub
SHIMANO FH-MT400-B, 32H, CL, 12x148mm, THRU Type AXLE
Rims
STARS J30D, Disc, 32H
Spokes
SAPIM Leader, Stainless Black
Tires
Schwalbe Johnny Watts Performance, 29x2.35", ADDIX
Brakes
Brakes
SHIMANO MT420, 4 piston, hydraulic disc brake
Cockpit
Stem
ONE ICR, Alloy, 31.8mm, 0°
Handlebar
ONE Alloy, 20mm rise, 31.8mm
Headset
ACROS AZX-1051, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°
Seat
Saddle
Selle Royal Vivo
Seatpost
ONE Race, Alloy, 30.9mm
Motor & Battery
Motor
BOSCH Performance Line CX, 85Nm
Battery
BOSCH PowerTube, 500Wh
Charger
BOSCH 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.344 mm | 1.344 mm | 1.289 mm | 1.238 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 806 mm | 806 mm | 826 mm | 846 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 134 mm | 134 mm | 134 mm | 134 mm |
| Stack | 625 mm | 625 mm | 625 mm | 625 mm |
| Reach | 465 mm | 465 mm | 485 mm | 505 mm |
| Top Tube Length | 598 mm | 610 mm | 630 mm | 650 |
| Seat Tube Angle | 78 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 393 mm | 420 mm | 440 mm | 490 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1251 mm | 1251 mm | 1271 mm | 1291 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
