Superior eXF 9049 R 2025
2025 E-bike
Estimate price |
7,793$
Weight | 22.95 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 130mm -
Fork DT Swiss F 535 ONE
-
Groupset XT -
Suspension Full -
Motor Shimano 600W 85Nm mid-drive -
Battery DARFON, 630Wh -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SU-E03-STEPS, Alu X6 Ultralite MTB Trail SUE03, Advanced e-MTB Geometry, Travel 130 mm, SHIMANO STEPS ready, Prepared to 630Wh integrated battery, 3D alloy one piece link, Alloy swingarm, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
DT Swiss F535 ONE, Tapered, 15x110mm axle, 140mm travel
Rear Shock
DT Swiss R535 ONE, size 210x50mm, ODL
Drivetrain
Rear Derailleur
SHIMANO XT RD-M8100, Shadow Plus Design
Shift Levers
SHIMANO DEORE XT SL-M8100-IR, RAPIDFIRE Plus, 12-speed
Cassette
SHIMANO DEORE CS-M6100, 12-speed, 10-51T
Crank
SHMANO FC-EM600
Bottom Bracket
STEPS, press-fit
Chain
SHIMANO DEORE CN-M6100
Wheels
Rims
DT Swiss H 1900 SPLINE®, CL, 15x110mm, Tubeless Ready
Tires
Schwalbe Nobby Nic Evo, SuperTrail, TL-Easy, 29x2.60", ADDIX SpeedGrip
Brakes
Brakes
SHIMANO XT M8120, 4 piston, hydraulic disc brake
Cockpit
Stem
ONE ICR, Alloy, 31.8mm, 0°
Handlebar
ONE Alloy, 20mm rise, 31.8mm
Headset
ACROS AZX-1051, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°
Seat
Saddle
Fizi:k Terra Aidon X5, Alloy
Seatpost
ONE Sport Dropper Post, Alloy, 30.9mm
Motor & Battery
Motor
SHIMANO STEPS EP6, 85Nm
Battery
DARFON, 630Wh
Charger
DARFON 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.347 mm | 1.305 mm | 1.305 mm | 1.29 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 736 mm | 764 mm | 775 mm | 792 mm |
| Rake | 40 mm | 43 mm | 43 mm | 42 mm |
| Trail | 123 mm | 120 mm | 120 mm | 121 mm |
| Stack | 590 mm | 599 mm | 608 mm | 618 mm |
| Reach | 438 mm | 459 mm | 466 mm | 479 mm |
| Top Tube Length | 599 mm | 625 mm | 635 mm | 650 |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1168 mm | 1196 mm | 1207 mm | 1224 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
