Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 85Nm mid-drive -
Battery DARFON, 504Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SU-E04-STEPS, Alu X6 Ultralite, Advanced eMTB Geometry, SHIMANO STEPS ready, Integrated battery, SR dropout, Boost 12x148 mm, Inner cable routing, Dropped seat post ready
Suspension Fork
RockShox Judy Silver TK, Tapered, SoloAir, 15x110mm axle, 120mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5100, Shadow Plus Design
Shift Levers
SHIMANO DEORE SL-M5100-IR, RAPIDFIRE Plus, 11-speed
Cassette
SHIMANO DEORE CS-M5100, 11-speed, 11-51T
Crank
SHMANO FC-EM600
Bottom Bracket
STEPS, press-fit
Chain
KMC e11T
Wheels
Front Hub
SHIMANO HB-MT410-B, 32H, CL, 15x110mm, THRU Type AXLE
Rear Hub
SHIMANO FH-MT400-B, 32H, CL, 12x148mm, THRU Type AXLE
Rims
STARS J30D, Disc, 32H
Spokes
SAPIM Galvanized Black
Tires
Schwalbe Smart Sam, KevlarGuard, 29x2.60"
Brakes
Brakes
SHIMANO MT420, 4 piston, hydraulic disc brake
Cockpit
Stem
ONE ICR, Alloy, 31.8mm, 0°
Handlebar
ONE Alloy, 25mm rise, 31.8mm
Headset
ACROS AZX-1051, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°
Seat
Saddle
Selle Royal Vivo
Seatpost
ONE Race, Alloy, 30,9mm
Motor & Battery
Motor
SHIMANO STEPS EP8, 85Nm
Battery
DARFON, 504Wh
Charger
DARFON 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.506 mm | 1.428 mm | 1.382 mm | 1.325 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 733 mm | 750 mm | 758 mm | 778 mm |
| Rake | 51 mm | 42 mm | 41 mm | 41 mm |
| Trail | 111 mm | 121 mm | 114 mm | 114 mm |
| Stack | 631 mm | 634 mm | 640 mm | 640 mm |
| Reach | 419 mm | 444 mm | 463 mm | 483 mm |
| Top Tube Length | 594 mm | 620 mm | 640 mm | 660 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66 ° | 66 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1173 mm | 1190 mm | 1198 mm | 1218 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
