Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 40mm -
Fork RockShox Rudy XPLR
-
Groupset GRX 800, GRX 600 -
Suspension Hardtail -
Motor Bosch 600W 55Nm mid-drive -
Battery BOSCH CompactTube, 400Wh -
Drivetrain 1 × 12 -
Brakes Shimano GRX 600 Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 165cm
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SU-E50-01, Alloy double-butted , Gravel Advanced Geometry, Smooth Welding, Disc Brake Flat mount, BB BSA 68mm, SH dropout, Integrated Cable Routing, Bike packing and mudguards ready
Suspension Fork
RockShox RUDY Base, Tapered, SoloAir, 12x100mm axle, 40mm travel
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX822, Shadow Plus Design
Shift Levers
SHIMANO GRX RX610, 12-speed
Cassette
SHIMANO SLX CS-M7101, 12-speed, 10-45T
Crank
ONE Race, Alloy
Bottom Bracket
BSA, 68mm, threaded
Chain
SHIMANO DEORE CN-M6100
Wheels
Rims
DT Swiss HG 1800 SPLINE®, CL, 12x100mm, Tubeless Ready
Tires
Schwalbe G-One Allround Performance, RaceGuard, TL-Easy, 45-622, ADDIX
Brakes
Brakes
SHIMANO GRX RX610, hydraulic disc brake
Cockpit
Stem
ONE Race ICR, Alloy, 31,8mm, -7°
Handlebar
ONE Alloy, X-Race Aero, 31.8mm, Reach 70mm, Drop 127mm, Flare 2°, Backsweep 6°
Headset
ACROS AZX-327R1S, ICR, ZS56/28.6 - ZS56/40, BlockLock 120°, Stainless Bearings
Seat
Saddle
Selle Royal SRX, 148mm
Seatpost
ONE Sport, Alloy, 30.9mm
Motor & Battery
Motor
BOSCH Performance SX, 55Nm
Battery
BOSCH CompactTube, 400Wh
Charger
BOSCH 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.467 mm | 1.492 mm | 1.511 mm | 1.51 mm | 1.532 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 604 mm | 605 mm | 610 mm | 610 mm | 634 mm |
| Rake | 44 mm | 45 mm | 44 mm | 29 mm | 43 mm |
| Trail | 80 mm | 76 mm | 77 mm | 89 mm | 71 mm |
| Stack | 553 mm | 564 mm | 574 mm | 595 mm | 616 mm |
| Reach | 377 mm | 378 mm | 380 mm | 394 mm | 402 mm |
| Top Tube Length | 530 mm | 540 mm | 550 mm | 570 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1039 mm | 1040 mm | 1045 mm | 1045 mm | 1070 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 165 cm | 171 cm | 181 cm | 191 cm | 200 cm |
