Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 165cm
SM
160cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Junior Geometry,1xOptimized, BB BSA, SR dropout,
Suspension Fork
SR Suntour XCT30, 1-1/8", Coil, QR Type, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO ACERA RD-M3020
Shift Levers
SHIMANO ALTUS SL-M315-8R, RAPIDFIRE Plus, 8-speed
Cassette
SHIMANO CS-HG31, 8-speed, 11-34T
Crank
ONE Sport, Alloy, 160mm, 32T
Bottom Bracket
Thun Ibex, BSA
Chain
KMC Z8.3
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-TX505, 32H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-TX505-8, 32H, CL, M10x135mm, QR Type
Rims
STARS J20S, Disc, 32H
Spokes
SAPIM Galvanized Black
Tires
Schwalbe Smart Sam, KevlarGuard, 27.5x2.10
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 25.4mm, 15°
Handlebar
ONE Alloy, 34mm rise, 25.4mm
Headset
ONE CHS0926 FIT8, 1-1/8", IS41/28.6 - IS41/30
Seat
Saddle
Selle Royal Mini Vivo
Seatpost
ONE Sport, Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.478 mm | 1.335 mm |
| Front Center | 632 mm | 672 mm |
| Rake | 43 mm | 42 mm |
| Stack | 566 mm | 566 mm |
| Reach | 383 mm | 424 mm |
| Top Tube Length | 547 mm | 586 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 343 mm | 393 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 90 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1064 mm | 1104 mm |
| Bottom Bracket Drop | 40 mm | 40 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 145 cm | 160 cm |
| Rider Max Height | 165 cm | 170 cm |
