Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 171cm
SM
169cm - 180cm
MD
175cm - 185cm
LG
180cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BF-FB-08, Carbon RR Mid Modulus, Road Advanced Geometry, Disc Brake Flat Mount, BSA 68, SH dropout, Thru Axle 142x12 mm, Inner cable routing, Di2 compatible.
Suspension Fork
RR Mid Modulus Carbon Fork, Rake 50mm
Drivetrain
Rear Derailleur
SHIMANO 105 RD-R7150, Shadow Design
Front Derailleur
SHIMANO 105 FD-R7150, Down Swing, Brazed-On Type
Shift Levers
SHIMANO 105 R7170, Di2, 2-speed
Cassette
SHIMANO 105 CS-R7101, 12 speed, 11-34T
Crank
SHIMANO 105 FC-R7100, Hollowtech II, 50-34T
Bottom Bracket
SHIMANO BB-RS501, BSA, shell 68mm
Chain
SHIMANO DEORE CN-M6100
Wheels
Front Hub
SHIMANO HB-RS470, 28H, CL, 12x100mm, THRU Type AXLE
Rear Hub
SHIMANO FH-RS470, 28H, CL, 12x142mm, THRU Type AXLE
Rims
DT Swiss R500, Disc, 28H, Tubeless Ready
Spokes
SAPIM Race, Stainless Black
Tires
Schwalbe One Performance, RaceGuard, 28-622, ADDIX
Brakes
Brakes
SHIMANO 105 R7170, hydraulic disc brake
Cockpit
Stem
ONE Race ICR, Alloy, 31,8mm, -7°
Handlebar
ONE Alloy, X-Race Aero, 31.8mm, Reach 70mm, Drop 127mm, Flare 2°, Backsweep 6°
Headset
ACROS AIX-525, ICR, OD56, IS52/28.6 - 40IPS
Seat
Saddle
Selle Royal SRX, 148mm
Seatpost
ONE Carbon, Offset 13mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.372 mm | 1.394 mm | 1.422 mm | 1.456 mm | 1.471 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 279 mm | 279 mm | 279 mm |
| Stack | 505 mm | 527 mm | 546 mm | 565 mm | 584 mm |
| Reach | 368 mm | 378 mm | 384 mm | 388 mm | 397 mm |
| Top Tube Length | 503 mm | 524 mm | 540 mm | 555 mm | 576 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 471 mm | 486 mm | 503 mm | 522 mm | 533 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 169 cm | 175 cm | 180 cm | 185 cm |
| Rider Max Height | 171 cm | 180 cm | 185 cm | 190 cm | 200 cm |
