Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 171cm
LG
169cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
Alloy 6061 T6, Disc Brake
Drivetrain
Shift Levers
microSHIFT N757, NEXUS INTER 7
Cassette
SHIMANO NEXUS, Sprocket, 20T
Crank
ONE Sport, Alloy, 46T
Bottom Bracket
Thun Topaz, BSA
Chain
KMC Z1 EPT
Pedals
Marwi SP-420
Wheels
Front Hub
SHIMANO DH-3D37-QR, 36H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO NEXUS SG-C3001-7D, 36H, CL, 135x187mm
Rims
STARS J19DC, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
CST OTIS, 37-622, Reflective Tape
Brakes
Brakes
Alhonga HJ-OD07, hydraulic disc brake
Cockpit
Handlebar
ONE Alloy, 20mm rise, 31.8mm
Headset
ONE MH505C1, 1-1/8"x26T, 25.4/44/30
Seat
Saddle
Selle Royal Nuvola
Seatpost
ONE, Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.504 mm | 1.468 mm |
| Front Center | 665 mm | 680 mm | 690 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 68 mm | 68 mm | 68 mm |
| Stack | 624 mm | 624 mm | 624 mm |
| Reach | 400 mm | 415 mm | 425 mm |
| Top Tube Length | 580 mm | 595 mm | 605 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 440 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 180 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1102 mm | 1117 mm | 1127 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 169 cm | 179 cm |
| Rider Max Height | 171 cm | 181 cm | 190 cm |
