Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork Zoom
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 171cm
LG
169cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Advanced Touring Geometry, Integrated Cable Routing, BB BSA
Suspension Fork
ZOOM 187D AMS, 1-1/8", Coil, QR Type, 60mm travel
Drivetrain
Rear Derailleur
SHIMANO XT RD-T8000, Shadow Design
Front Derailleur
SHIMANO DEORE FD-T6000, Top Swing, Down Pull
Shift Levers
SHIMANO XT SL-T8000, 3-speed
Cassette
SHIMANO CS-HG500, 10-speed, 11-34T
Crank
SHIMANO FC-T521L, 48-36-26T
Bottom Bracket
SHIMANO BB-ES300, BSA, shell 73mm
Chain
KMC X10
Pedals
Marwi SP-823
Wheels
Front Hub
SHIMANO DH-3D37-QR, 36H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-TX505-8, 36H, CL, M10x135mm, QR Type
Rims
STARS J19DC, Disc, 36H
Spokes
SAPIM Leader, Stainless Black
Tires
Schwalbe Road Cruiser, KevlarGuard, 40-622, Reflective tape
Brakes
Brakes
SHIMANO MT410, hydraulic disc brake
Cockpit
Stem
ONE, Alloy, 31.8mm, Adjustable
Handlebar
ONE Alloy, 20mm rise, 31.8mm
Headset
FSA TH-807ST, Semi-Cartrige, 1-1/8
Seat
Saddle
Selle Royal Ariel
Seatpost
ONE, Alloy, Suspension, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.504 mm | 1.468 mm |
| Front Center | 665 mm | 680 mm | 690 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 68 mm | 68 mm | 68 mm |
| Stack | 624 mm | 624 mm | 624 mm |
| Reach | 400 mm | 415 mm | 425 mm |
| Top Tube Length | 580 mm | 595 mm | 605 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 440 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 180 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1102 mm | 1117 mm | 1127 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 169 cm | 179 cm |
| Rider Max Height | 171 cm | 181 cm | 190 cm |
