Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
XS
140cm - 165cm
SM
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu X6 Ultralite, Race Geometry, Integrated Cable Routing, BB92, SR dropout, Boost Thru axle 148x12mm, Inner cable routing.
Suspension Fork
RockShox Judy Silver TK R, Tapered, SoloAir, 15x110mm axle, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7100, Shadow Plus Design
Shift Levers
SHIMANO DEORE SL-M6100-IR, RAPIDFIRE Plus, 12-speed
Cassette
SHIMANO DEORE CS-M6100, 12-speed, 10-51T
Crank
ONE Race, Alloy, 165mm, 32T
Bottom Bracket
SHIMANO BB-MT500PA, PressFit, shell 41x92mm
Chain
SHIMANO DEORE CN-M6100
Wheels
Front Hub
SHIMANO HB-MT410-B, 28H, CL, 15x110mm, THRU Type AXLE
Rear Hub
SHIMANO FH-MT410-B, 28H, CL, 12x148mm, THRU Type AXLE
Rims
STARS J20S, Disc, 28H
Spokes
SAPIM Laser/Race, Stainless Black
Tires
Schwalbe Racing Ray Performance, TwinSkin, TL-Ready, 27.5x2.25", ADDIX
Brakes
Brakes
SHIMANO MT410, hydraulic disc brake
Cockpit
Handlebar
ONE Alloy Integrated Cockpit
Headset
ACROS AZX-212 R5, ZS44/28.6 - ZS56/40
Seat
Saddle
Selle Royal Mini Vivo
Seatpost
ONE Race, Carbon, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.492 mm | 1.348 mm |
| Front Center | 633 mm | 674 mm |
| Rake | 43 mm | 43 mm |
| Stack | 570 mm | 570 mm |
| Reach | 382 mm | 423 mm |
| Top Tube Length | 545 mm | 586 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 330 mm | 393 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 90 mm |
| Chainstay Length | 418 mm | 418 mm |
| Wheelbase | 1048 mm | 1089 mm |
| Bottom Bracket Drop | 40 mm | 40 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 140 cm | 155 cm |
| Rider Max Height | 165 cm | 170 cm |
