Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Groupset Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 T6 Double Butted, Smooth Welding, Sport Geometry, Geometry, Integrated Cable Routing, BB BSA 73 mm, IDK dropout,
Suspension Fork
Suspension Air fork, AHEAD 1-1/8", QR Type, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M4120, Shadow Design
Front Derailleur
SHIMANO DEORE FD-M4100-M, Side Swing, Front Pull
Shift Levers
SHIMANO DEORE SL-M5100-L, RAPIDFIRE Plus, 2-speed
Cassette
SHIMANO DEORE CS-M4100, 10-speed, 11-42T
Crank
ONE Race, Alloy, 36-26T
Bottom Bracket
SHIMANO BB-MT501, BSA, shell 68/73mm
Chain
KMC X10
Pedals
Marwi SP-610
Wheels
Front Hub
SHIMANO HB-QC300, 32H, CL, M9X100mm, QR Type
Rear Hub
SHIMANO FH-QC300-HM, 32H, CL, M10X135mm, QR Type
Rims
STARS J25D, Disc, 32H
Spokes
SAPIM Galvanized Black
Tires
CST Jack Rabbit, 29x2.25"
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake
Cockpit
Stem
ONE Sport, Alloy, 31.8mm, -8°°
Handlebar
ONE Alloy, 12mm rise, 31.8mm
Headset
ONE CHH1505, 1-1/8“, ZS44/28.6 - ZS56/30
Seat
Saddle
Selle Royal Vivo
Seatpost
ONE Sport, Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.437 mm | 1.387 mm | 1.327 mm | 1.35 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 730 mm | 757 mm | 777 mm | 790 mm |
| Rake | 66 mm | 67 mm | 67 mm | 66 mm |
| Trail | 87 mm | 86 mm | 86 mm | 87 mm |
| Stack | 608 mm | 617 mm | 617 mm | 636 mm |
| Reach | 423 mm | 445 mm | 465 mm | 471 mm |
| Top Tube Length | 580 mm | 605 mm | 625 mm | 635 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 120 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1143 mm | 1170 mm | 1190 mm | 1203 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
