Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon MTB Race Pro Mid Modulus,Advanced Race Geometry, Integrated Cable Routing, BB92, SR dropout, Boost Thru Axle 148x12 mm
Suspension Fork
RockShox Recon Silver RL R, Tapered, SoloAir, 15x110mm axle, 100mm travel
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100, Shadow Plus Design
Shift Levers
SHIMANO DEORE SL-M6100-IR, RAPIDFIRE Plus, 12-speed
Cassette
SHIMANO DEORE CS-M6100, 12-speed, 10-51T
Crank
SHIMANO FC-MT510, 34T
Bottom Bracket
SHIMANO BB-MT500PA, PressFit, shell 41x92mm
Chain
SHIMANO DEORE CN-M6100
Wheels
Front Hub
SHIMANO HB-TC500-15-B, 32H, CL, 15x110mm, THRU Type AXLE
Rear Hub
SHIMANO FH-TC500-MS-B, 32H, CL, 12X148mm, THRU Type AXLE
Rims
WTB, KOM LIGHT TEAM i25, Disc, 32H, Tubeless Ready
Spokes
SAPIM Laser/Race, Stainless Black
Tires
Schwalbe Racing Ralph Performance, 29x2.25", ADDIX
Brakes
Brakes
SHIMANO MT410, hydraulic disc brake
Cockpit
Stem
ONE Race ICR, Alloy, 31,8mm, -7°
Handlebar
ONE Race, Alloy, 5mm rise, 31.8mm
Headset
ACROS AZX-1090 ICR, ZS56/28.6 - ZS56/40, BlockLock 150°
Seat
Saddle
Fizi:k Ridon X5, Alloy
Seatpost
ONE Race, Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.377 mm | 1.325 mm | 1.291 mm | 1.257 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 723 mm | 745 mm | 769 mm | 793 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 113 mm | 113 mm | 113 mm | 113 mm |
| Stack | 599 mm | 603 mm | 613 mm | 622 mm |
| Reach | 435 mm | 455 mm | 475 mm | 495 mm |
| Top Tube Length | 590 mm | 615 mm | 635 mm | 645 mm |
| Seat Tube Angle | 75.5 ° | 75.2 ° | 75.4 ° | 76.4 ° |
| Seat Tube Length | 393 mm | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 90 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1147 mm | 1169 mm | 1193 mm | 1217 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | 57 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
