Surface 604 2020 Rook 2020
2020 E-bike
Estimate price |
1,999$
Weight | 25.76 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Alivio -
Suspension Hardtail -
Motor Bafang 500W 50Nm hub-drive -
Battery Weight: 7.7 lbs (3.49 kg), Brand: Samsung 18650 (2400mA or 3200mA Cells), Reention Dorado Casing, Voltage: 48 volts, Amp Hours: 10.4 ah (Optional 14ah), Watt Hours: 499.2 wh (Optional 672wh), Chemistry: Lithium-ion -
Drivetrain 1 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Alloy
Suspension Fork
SR Suntour XCT Spring Suspension, 80mm Travel, 28mm Steel Stanchions, Lockout Adjust, Compression Adjust, Preload Adjust, 100mm Hub Spacing, 9mm Skewer with Quick Release
Drivetrain
Shift Levers
Shimano Alivio Triggers on Right (Two-Way High Lever, Three-Shift Low Lever), Shift Display Readout
Cassette
9 Speed 1x9 Shimano Alivio Derailleur, Shimano CS-HG201-9 Cassette 11-34 Tooth
Crank
Samox, Forged Alloy, Sealed Cartridge Bearings, Hollow Spindle, 42 Tooth Steel Chainring
Pedals
Wellgo Aluminum Alloy Platform with Rubber Tread
Wheels
Rims
Double Wall, Aluminum Alloy, 25mm Outer Width, 36 Hole, Black
Spokes
Stainless Steel, 13 Gauge, Black
Tires
Kenda Kranium, 26" x 2.10" (54-559)
Cockpit
Stem
Satori UP2+, Adjustable Angle 0° to 90°, 70mm Base Height, 110mm Length, 20mm Stack Height, Two 10 mm Risers, 31.8mm Clamp Diameter
Handlebar
Aluminum Alloy, 20mm Low-Rise, 630 mm Length, 6° Backsweep
Grips
Stitched Faux Leather, Ergonomic, Black
Headset
Integrated, Sealed Cartridge, Straight 1-1/8"
Seat
Saddle
Selle Royal FreeWay, Gel
Seatpost
Aluminum Alloy with Forged Single-Bolt Clamp
Motor & Battery
Motor
Brand: Bafang RM G360.500.DC, Type: Rear-Mounted Geared Hub, Nominal Output: 500 watts, Peak Output: 750 watts, Torque: 50 Newton meters
Battery
Weight: 7.7 lbs (3.49 kg), Brand: Samsung 18650 (2400mA or 3200mA Cells), Reention Dorado Casing, Voltage: 48 volts, Amp Hours: 10.4 ah (Optional 14ah), Watt Hours: 499.2 wh (Optional 672wh), Chemistry: Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm |
|---|---|
| Wheels | 26" |
| Rider Min Height | 120 cm |
About this model
2020 Rook completes the Surface604 E 2020 model. Surface 604 released 1 e-bike variation of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter e-bikes average price
Our math shows that the average cost of a dependable Commuter e-bike is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When Surface 604 released this model in 2020, its price was 1999$. Comparing the average cost of a Commuter e-bike to this one, you will see that 2020 Rook price is 28.51% smaller.
Commuter e-bikes average weight
On a deeper look, we notice that the average weight of a Commuter e-bike is 25.2 kg (55.56 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 25.76 kg (56.79 lbs), Surface 604 e-bike is slightly heavier than average. In other words, this model is 2.22% heavier than the average Commuter e-bike.
Overview of components
Fork
This e-bike has the SunTour XCT fork installed. The fork’s travel is 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
2020 Rook has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the e-bike.
Wheels size
When leaving the production line, the 2020 Rook model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Surface 604 2020 Rook is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
