Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 26" -
Groupset GX, NX -
Suspension Rigid -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerPack 500 -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Big Easy Frame for Bosch Mid Drive
Suspension Fork
Surly Big Easy Fork
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
SRAM NX 11 speed
Cassette
SunRace CSMS7 11-42
Crank
Miranda for Big Easy
Bottom Bracket
included in Bosch Unit
Chain
KMC X11e
Wheels
Front Hub
Shimano M525, 32h, QR
Rear Hub
Shimano M525, 32h, QR
Rims
WTB STS i29 TCS
Tires
Surly ExtraTerrestrial 26x2.5" Tubeless Ready
Brakes
Brakes
Tektro Orion 4 Piston HD-M745
Brake Levers
Tektro
Cockpit
Stem
ProMax 4-bolt 31.8mm clamp
Handlebar
Salsa Bend 17 degree. No logo
Grips
Velo single lock-on
Headset
Cane Creek ViscoSet [tuned for Surly Big Easy] upper. 40 series lower
Seat
Saddle
WTB Volt
Seatpost
ProMax 2-Bolt. 30.9mm
Motor & Battery
Motor
Bosch Performance CX [20m/h]
Battery
Bosch PowerPack 500
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.39 mm |
| Front Center | 661 mm | 693 mm | 720 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 75 mm | 74 mm | 75 mm |
| Stack | 573 mm | 601 mm | 629 mm |
| Reach | 417 mm | 437 mm | 454 mm |
| Top Tube Length | 596 mm | 626 mm | 651 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 406 mm | 432 mm | 508 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 827 mm | 827 mm | 827 mm |
| Wheelbase | 1486 mm | 1518 mm | 1545 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm |
| Standover Height | 729 mm | 777 mm | 827 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Big Easy is a Surly E Big Easy model. 4 e-bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Long Tail Cargo e-bikes average price
Our math shows that the average cost of a dependable Long Tail Cargo e-bike is 3082$. However, you could also get a good Long Tail Cargo e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Surly released this model in 2023, its price was 5249$. In conclusion, this e-bike price is 70.31% more expensive than the price of the average Long Tail Cargo e-bike.
Big Easy components
Wheels
The Big Easy 2023 e-bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your e-bike. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
