Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset NX -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Lowside Frame, 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Suspension Fork
Surly Lowside Fork, 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Surly 17t w/ spacer kit
Crank
SRAM NX 32t
Bottom Bracket
SRAM PS
Chain
KMC X10
Wheels
Front Hub
Novatec 15x110
Rear Hub
Novatec 12x148
Rims
WTB ST i35 TCS
Tires
Maxxis Rekon+ 27.5x2.8 60tpi
Brakes
Brakes
Tektro Hydro M275/276
Brake Levers
Tektro
Cockpit
Stem
Sunday Freeze top load 22.2mm clamp
Handlebar
Surly Sunrise
Headset
Cane Creek
Seat
Saddle
Selle Italia Black
Seatpost
2 Bolt, 30.9mm
