Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Pinion -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
170cm - 182cm
LG
180cm - 190cm
XL
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Suspension Fork
4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
Drivetrain
Rear Derailleur
Pinion C1.9 XR 9spd Gearbox
Front Derailleur
N/A
Shift Levers
Pinion Rotary Shifter
Cassette
34t aluminum ring
Crank
Pinion for Surly crankset 34T, with Pinion high-offset spider
Bottom Bracket
Pinion Gearbox
Chain
KMC X10 EPT Anti-Rust
Wheels
Front Hub
Novatec 12x197mm, Thru-Axle, 32h
Rear Hub
Novatec 12x197mm, Thru-Axle, 32h
Rims
Surly Clown Royal 24", 100mm wide
Tires
Surly Molenda Tire 24 X 6.2”, 60tpi, Tubeless Ready
Brakes
Brakes
Tektro HD-M285, Tektro 180/180, 6-Bolt
Cockpit
Stem
Promax, 31.8, 4-bolt
Handlebar
Surly Terminal
Headset
Cane Creek 40
Seat
Saddle
WTB Volt Medium
Seatpost
TransX YSP15JL Dropper, 125mm travel (100mm travel on SM)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.452 mm | 1.443 mm | 1.408 mm | 1.376 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 656 mm | 689 mm | 721 mm | 752 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 578 mm | 606 mm | 625 mm | 644 mm |
| Reach | 398 mm | 420 mm | 444 mm | 468 mm |
| Top Tube Length | 575 mm | 605 mm | 635 mm | 665 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 368 mm | 419 mm | 480 mm | 521 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 120 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 562 mm | 562 mm | 562 mm | 562 mm |
| Wheelbase | 1215 mm | 1248 mm | 1280 mm | 1311 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 736 mm | 769 mm | 793 mm | 801 mm |
| Wheels | 24" | 24" | 24" | 24" |
| Rider Min Height | 162 cm | 170 cm | 180 cm | 188 cm |
| Rider Max Height | 172 cm | 182 cm | 190 cm | 198 cm |
