Tern GSD P00 2024
2024 E-bike
Estimate price |
7,095$
Weight | 35.75 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 50mm -
Fork Suntour
-
Groupset Gates CDX -
Suspension Hardtail -
Motor Bosch 85Nm mid-drive -
Battery Bosch 500 PowerPack, Fast Swap, Dual Battery bays, optional 2 x 500 Wh max capacity -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Magura MT5 Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tern GSD, 6061-AL, patented MultiTruss design, DIN 79010 certified: 210 kg
Suspension Fork
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 50 mm travel, EFBE approved: 210 kg
Drivetrain
Shift Levers
Enviolo, Twist
Cassette
Gates CDX, precision CNC machined cog
Crank
Tern GSD, Gates CDX CNC machined beltring
Bottom Bracket
Motor integrated
Chain
Gates Carbon Drive CDX belt
Chain Guide
Tern GSD, full chain cover
Pedals
Urban with non-slip surface, sealed bearings
Wheels
Front Hub
Tern Atlas, Cooling Fins, Boost Thru-Axle, sealed cartridge bearings
Rear Hub
Enviolo Heavy Duty, 380% continuously variable range, Boost
Rims
Tern Atlas, ultra wide 36 mm, dual reinforced joint
Tires
F: Schwalbe Big Ben Plus, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, Green Guard puncture protection, Reflex
Brakes
Brakes
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads
Brake Levers
Magura MT5 e-stop, hydraulic, with brake light sensor
Cockpit
Stem
Tern Andros, adjustable, forged construction, patented technology
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Headset
Tern Flux Pro Taper by FSA, 1.5", angular contact bearings, Physis integrated
Seat
Saddle
Tern GSD by Velo
Seatpost
Tern VLT (Very Large Telescope) with LightAction levers
Motor & Battery
Motor
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
Battery
Bosch 500 PowerPack, Fast Swap, Dual Battery bays, optional 2 x 500 Wh max capacity
Charger
220V, 4A (EU); 100-240V, 4A (US)
