Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 170mm -
Fork Fox Factory Float 38
-
Groupset GX Eagle AXS -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery SHIMANO EP8 - 85 Nm (250W) - integrated Shimano 630 Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
THOK - Unidirectional full carbon fiber, headtube tapered 1.8, 29"/27,5" geometry, integrated down tube battery, UDH Hanger tecnology, enclosed internal cable, fully sealed cartridge bearing, 170 mm travel
Suspension Fork
FOX - 38 Float Factory Kashima 29" Boost, GRIP2, 180 mm travel.
Rear Shock
FOX - X2 Float Factory Kashima, 2 Pos Adj, THOK Custom tuned, 230x65
Drivetrain
Rear Derailleur
SRAM - GX Eagle AXS
Shift Levers
SRAM - GX Eagle AXS
Cassette
SRAM - X-Glide 12 Speed, 10-50T
Crank
Flat polyethylene pedals
Chain
SRAM - Eagle 12V
Wheels
Rims
CRANKBROTHERS - Synthesis Alloy Ebike, front 29"x 30 mm ; rear 27.5"x 35 mm
Tires
MAXXIS - Assegai 29x2.6 ant. e 27.5×2.6 post. 3C / EXO+ / TR
Brakes
Brakes
SHIMANO - Deore XT, 4 piston, 203mm rotors
Cockpit
Stem
THOK - Alloy with front clamp oversize 35 mm, ext 37 mm
Handlebar
RENTHAL - Fatbar Carbon, rise 20 mm, width 800mm
Grips
THOK - Lock-On grip, regular size
Seat
Saddle
THOK Fit in hollow Cr.Mo rail
Seatpost
THOK dropper post micro height adjustable, remote control (S/125 mm - M/150 - L/XL 170 mm)
Motor & Battery
Motor
SHIMANO EP8 - 85 Nm (250W) - integrated Shimano 630 Wh
Battery
SHIMANO EP8 - 85 Nm (250W) - integrated Shimano 630 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 57cm | 58cm | 61cm | 63cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.37 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 361 mm | 361 mm | 361 mm | 361 mm |
| Front Center | 785 mm | 796 mm | 825 mm | 850 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 132 mm | 130 mm | 133 mm |
| Stack | 619 mm | 627 mm | 640 mm | 658 mm |
| Reach | 445 mm | 457 mm | 477 mm | 497 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 385 mm | 415 mm | 430 mm | 475 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 99 mm | 106 mm | 118 mm | 130 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1237 mm | 1248 mm | 1277 mm | 1302 mm |
| Bottom Bracket Drop | 9 mm | 9 mm | 9 mm | 9 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
GRAM-RC is part of the Thok E Gram Rc model. Thok launched 1 e-bike of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.3 kg (51.37 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 23.3 kg (51.37 lbs), Thok e-bike is equally heavier with average. In other words, this model is 0% heavier than the average Enduro e-bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
GRAM-RC components
Fork
This e-bike has the Fox Factory Float 38 fork installed. The fork’s travel is 180mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this e-bike is FOX – X2 Float Factory Kashima, with a travel distance of 170mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the GRAM-RC model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The GRAM-RC has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
A dropper post is included with the GRAM-RC. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
