Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery SHIMANO STEPS E7000 - 60 Nm (250W) waterproof battery 504 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
140cm - 166cm
MD
163cm - 176cm
LG
173cm - 186cm
XL
184cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy frame 6061 T4 T6, forged and CNC parts, hydroformed tubes
Suspension Fork
RockShox - RECON RL,29", Boost, 120 mm
Drivetrain
Rear Derailleur
Shimano Deore
Shift Levers
Cyclo Computer SC-E5000
Cassette
Shimano Deore 10S (11-42)
Crank
FSA chainring 34T
Chain
Shimano 10S
Pedals
Polyethylene pedals
Wheels
Rims
Thok with Novatec hub
Tires
Maxxis - IKON 29x2.6, 60tpi, EXO/TR
Brakes
Brakes
SRAM - Level, hydraulic disk, 200/180 mm
Cockpit
Stem
THOK 60 mm
Handlebar
THOK Oversize 31.8 mm, 760 mm wide
Seat
Saddle
THOK - Fit in Chromo
Seatpost
THOK
Motor & Battery
Motor
SHIMANO STEPS E7000 - 60 Nm (250W) waterproof battery 504 Wh
Battery
SHIMANO STEPS E7000 - 60 Nm (250W) waterproof battery 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 322 mm | 322 mm | 322 mm | 322 mm |
| Front Center | 704 mm | 719 mm | 748 mm | 772 mm |
| Reach | 390 mm | 410 mm | 431 mm | 448 mm |
| Top Tube Length | 569 mm | 590 mm | 616 mm | 638 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 374 mm | 434 mm | 470 mm | 505 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 150 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1139 mm | 1155 mm | 1184 mm | 1208 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 140 cm | 163 cm | 173 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 199 cm |
About this model
MIG-HT is part of the Thok E Mig Ht model. 2 e-bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
This e-bike was released in 2023 and its price was 3599$. Doing a quick comparison, we notice that MIG-HT price is 6.95% higher than the average cost of a Trail e-bike.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Thok MIG-HT 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The MIG-HT comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 140 cm – 199 cm (4.59 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
