Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Rhythm Float 36
-
Groupset SLX -
Suspension Full -
Motor Bosch 750W 100Nm mid-drive -
Battery BOSCH – Performance Line CX (750W – 100Nm) – Internal BOSCH Powetube battery 800 Wh (compatibility with PT600 and PT400) – *optional Bosch Powermore range extender 250Wh. -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
THOK – Unidirectional Full Carbon Fiber, headtube tapered 1.5, 29” geometry with flipchip, 27,5” compatibility, integrated down tube battery, UDH Hanger tecnology, enclosed internal cable, fully sealed cartridge bearing, 150 mm travel.
Suspension Fork
FOX – 36 Float Rhythm, E-Optimized, 29? Boost, GRIP, 160 mm travel, 44mm offset, 1.5 tapered.
Rear Shock
FOX – Float Rhythm, 2 Pos Evol-LV, THOK Custom tuned, 210×55.
Drivetrain
Rear Derailleur
SHIMANO – SLX 12S.
Shift Levers
SHIMANO – 12S.
Cassette
SHIMANO – 12S 10-51T.
Crank
FSA 165 mm with chainring 34T.
Chain
SHIMANO – 12S.
Pedals
Flat polyethylene pedals.
Wheels
Rims
Front: THOK DRIFT 29?x 30 mm, 15×110., Rear: THOK DRIFT 29?x 30mm, 12×148, MS freehub body.
Tires
Front: SCHWALBE – Albert Trail Pro 29? x 2.6 Soft TLR., Rear: SCHWALBE – Albert Trail Pro 29? x 2.6 Soft TLR.
Brakes
Brakes
SHIMANO – DEORE, 4 pistons, SHIMANO SM-RT66 203mm rotors.
Cockpit
Stem
THOK – Alloy with front clamp oversize 35 mm, ext 50 mm.
Handlebar
THOK – Alloy 6061 oversize 35 mm DB, rise 20 mm, width 780mm.
Grips
THOK – Lock-On grips.
Headset
ACROSS – BlockLock 135°.
Seat
Saddle
THOK – Fit in hollow Cr.Mo rail.
Seatpost
THOK – dropper post micro height adjustable, remote control (S/125 mm – M/170 mm- L/XL 200 mm).
Motor & Battery
Motor
BOSCH – Performance Line CX (750W – 100Nm) – Internal BOSCH Powetube battery 800 Wh (compatibility with PT600 and PT400) – *optional Bosch Powermore range extender 250Wh.
Battery
BOSCH – Performance Line CX (750W – 100Nm) – Internal BOSCH Powetube battery 800 Wh (compatibility with PT600 and PT400) – *optional Bosch Powermore range extender 250Wh.
