Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
157cm - 169cm
SM
166cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tommaso 6061 SLA Aluminum Compact Road Frame
Suspension Fork
Tommaso HCT Carbon Fiber Fork with 1 1/8€ Aluminum Steer Tube
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 (10-spd)
Front Derailleur
Shimano Tiagra 4700 (2-spd)
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 4700 - 11-32t - (10spd)
Crank
Shimano Tiagra 50/34t Compact
Bottom Bracket
Shimano Tiagra 4700
Chain
KMC X10 (10-Speed)
Pedals
Composite Flat
Wheels
Rims
Tommaso Corsa TC-40D
Tires
CST Tirent 700x40c All Terrain
Brakes
Brakes
Avid BB5 Disc
Brake Levers
Shimano Tiagra 4700
Cockpit
Stem
Tommaso TRS Ultralight Sport Series
Handlebar
Tommaso TRS Ultralight Sport Series
Headset
1-1/8" Threadless Integrated
Seat
Saddle
WTB Volt - Tommaso Logo
Seatpost
Tommaso TRS Ultralight Race Series Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 524 mm | 544 mm | 559 mm | 574 mm | 589 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 972 mm | 988 mm | 998 mm | 1008 mm | 1023 mm |
| Standover Height | 724 mm | 749 mm | 769 mm | 794 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 169 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Illimitate Disc completes the Tommasso Illimitate model. There are 2 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1139$. Comparing this to the average Gravel bike price, we see that the price is 116.15% smaller.
Illimitate Disc components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Tommasso Illimitate Disc 2020, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Illimitate Disc comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Illimitate Disc comes in 5 sizes, that range from 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
