Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
157cm - 169cm
SM
166cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tommaso 6061 SLA Aluminum Compact Road Frame
Suspension Fork
Tommaso HCT Carbon Fiber Fork with 1 1/8€ Aluminum Steer Tube
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 (10-spd)
Front Derailleur
Shimano Tiagra 4700 (2-spd)
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 4700 - 11-32t - (10spd)
Crank
Shimano Tiagra 50/34t Compact
Bottom Bracket
Shimano Tiagra 4700
Chain
KMC X10 (10-Speed)
Pedals
Composite Flat
Wheels
Rims
Tommaso Corsa TC-40D
Tires
CST Tirent 700x40c All Terrain
Brakes
Brakes
Avid BB5 Disc
Brake Levers
Shimano Tiagra 4700
Cockpit
Stem
Tommaso TRS Ultralight Sport Series
Handlebar
Tommaso TRS Ultralight Sport Series
Headset
1-1/8" Threadless Integrated
Seat
Saddle
WTB Volt - Tommaso Logo
Seatpost
Tommaso TRS Ultralight Race Series Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 524 mm | 544 mm | 559 mm | 574 mm | 589 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 972 mm | 988 mm | 998 mm | 1008 mm | 1023 mm |
| Standover Height | 724 mm | 749 mm | 769 mm | 794 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 169 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Illimitate Disc is part of the Tommasso Illimitate model. 2 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 1174$. In conclusion, this bike price is 109.71% lower than the price of the average Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Tommasso Illimitate Disc 2021, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Tommasso Illimitate Disc is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Illimitate Disc comes in 5 sizes, that range from 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
