Transition PBJ Complete 2025
2025 Mountain
Estimate price |
1,999$
Weight | 11.92 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 100mm -
Fork Marzocchi Bomber DJ
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes SRAM Level Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PBJ Chromoly Steel
Suspension Fork
Marzocchi Bomber DJ, (100mm)
Drivetrain
Cassette
12t Single Cog
Crank
Samox BMX 3-Piece Chromoly, (25t/170mm)
Bottom Bracket
73mm BSA Threaded
Chain
KMC K1 Wide
Wheels
Front Hub
Novatech D791SB-15/D256SBT
Rear Hub
Novatech D791SB-15/D256SBT
Rims
Kinlin DDT32
Spokes
Pillar 14g
Tires
Front: Maxxis Ikon (2.2), Rear: Maxxis Ikon (2.2)
Brakes
Brakes
SRAM Level (Rear Only)
Cockpit
Stem
Spank Spoon (40mm)
Handlebar
Spank Spoon, Short/Long (785x40mm), X-Long (785x60mm)
Grips
ODI Longneck Lock-On
Headset
FSA No.10/7B/44
Seat
Saddle
SDG Patriot I-Beam
Seatpost
SDG I-Beam
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Short | Long | X-Long |
|---|---|---|---|
| Stack Reach Ratio | 1.371 mm | 1.293 mm | 1.224 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 675 mm | 700 | 725 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 92 mm | 92 mm | 92 mm |
| Stack | 569 mm | 569 mm | 569 mm |
| Reach | 415 mm | 440 mm | 465 mm |
| Top Tube Length | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 338 mm | 338 mm | 338 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm |
| Chainstay Length | 388 mm | 388 mm | 400 mm |
| Wheelbase | 1062 mm | 1087 mm | 1124 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Standover Height | 620 mm | 620 mm | 620 mm |
| Wheels | 26" | 26" | 26" |
