Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Groupset SLX, Deore -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminum w/semi-integrated head tube, butted and hydroformed tubing, internal front derailleur cable routing, replaceable derailleur hanger
Drivetrain
Rear Derailleur
Shimano Deore SLX Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore, 10 speed
Cassette
Shimano HG62 11-36, 10 speed
Crank
Shimano M522, 42/32/24
Pedals
Wellgo nylon platform
Wheels
Rims
Shimano RM66 alloy hubs w/Bontrager AT-850 32-hole double-walled rims
Tires
Bontrager XR2, 26x2.20"
Brakes
Brakes
Shimano M395 hydraulic disc brakes
Cockpit
Stem
Bontrager Race Lite, 31.8mm, 7 degree
Handlebar
Bontrager Low Riser, 31.8mm, 15mm rise, 9 degree sweep
Headset
1-1/8" threadless, semi-integrated, semi-cartridge bearings
Seat
Saddle
Bontrager Evoke 1
Seatpost
Bontrager SSR, 31.6mm, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
4700 Disc completes the Trek 4700 model. There are 2 bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
4700 Disc components
Wheels
When it comes to wheels, the 4700 Disc bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek 4700 Disc is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
