Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore, Dura-Ace -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trek butted Cro-Moly
Suspension Fork
Cro-Moly Touring
Drivetrain
Rear Derailleur
Shimano Deore LX
Front Derailleur
Shimano Deore LX
Shift Levers
Shimano Dura-Ace, bar end control, 9 speed
Cassette
Shimano HG50 11-32, 9 speed
Crank
Shimano Trekking M453 48/36/26
Pedals
Shimano M520, clipless
Wheels
Rims
Shimano Deore LX hubs; Bontrager Camino rims
Tires
Bontrager Race Lite Hardcase, 700x32c
Brakes
Brakes
Avid SD-5 w/Dia-Compe 287 Aero levers
Cockpit
Stem
Bontrager Race Lite OS, 7 degree, 31.8mm
Handlebar
Bontrager Race VR OS
Headset
VP aheadset
Seat
Saddle
Bontrager Select City
Seatpost
Bontrager Alloy, Infinite Angle Adjustability
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
520 is part of the Trek 520 model. There are 39 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Touring bikes average price
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The wheels on 520 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek 520 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
