Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
400 Series OCLV Carbon, E2, BB90, DuoTrap compatible, IsoSpeed
Suspension Fork
Trek IsoSpeed carbon, E2
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra, braze-on
Shift Levers
Shimano Tiagra, 10 speed
Cassette
Shimano Tiagra, 12-30, 10 speed
Crank
Shimano Tiagra, 50/34 (compact)
Bottom Bracket
BB90, 90.5mm, press-fit
Pedals
Nylon body w/alloy cage, toe-clip/strap
Wheels
Rims
Bontrager alloy front hub, Formula TK32 alloy rear hub, Bontrager Tubeless Ready rims
Tires
Bontrager AW2 Hard-Case Lite, aramid bead, 700x25c
Brakes
Brakes
Alloy dual-pivot brakes, Tektro CL520 adjustable-reach alloy levers
Cockpit
Stem
Bontrager Blendr Elite, w/computer & light mounts, 31.8mm, 7 degree
Handlebar
Bontrager Satellite Plus IsoZone, 31.8mm, 15mm rise
Headset
FSA Integrated, sealed cartridge bearings, 1-1/8" top, 1.5" bottom
Seat
Saddle
Bontrager Paradigm 1
Seatpost
Bontrager alloy, 2-bolt head, 27.2mm, 8mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
7.7 FX belongs to the Trek 77 model. There are 11 bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for General Road bikes
According to our math, the average price for a trustworthy General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Trek 7.7 FX 2016, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek 7.7 FX is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
