Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Groupset XT, SLX -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Platinum Series 6061 T6 aluminum, G2 Geometry, butted and hydroformed tubing, cold-forged dropouts & BB
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano XT
Shift Levers
Shimano SLX
Cassette
SRAM PG970 11-32 9speed
Pedals
Custom Crank Bros Candy C w/cleats
Wheels
Rims
Bontrager disc, Shimano M525 hubs, Bontrager SSR rims 32h
Tires
Bontrager XDX 26x2.1, 120 TPI, aramid folding bead, Tubeless Ready
Brakes
Brakes
Avid Elixir 5 Hydraulic Disc, 160mm rotors
Cockpit
Stem
Bontrager Race X Lite OS, 7d rise, 31.8mm clamp
Handlebar
Bontrager Race Lite Big Sweep, 640mm width, 12d backsweep, 31.8mm
Headset
1-1/8" threadless, semi-integrated, semi-cartridge bearings
Seat
Saddle
Bontrager Race Lite, superlight hollow cromoly rails
Seatpost
Bontrager Race Lite, 2014 aluminum shaft, infinite adjust Bontrager head
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Big Sur completes the Trek Big Sur model. Trek released 21 bikes variations of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Big Sur components
Wheels
The Big Sur 2010 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Big Sur comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
