Trek District+ 5 2025
2025 E-bike
Estimate price |
6,283$
Weight | 27.1 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High-performance hydroformed alloy, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc
Suspension Fork
SR Suntour Mobie 34, air spring, rebound and compression adjust, tapered alloy steerer, 100x15 mm thru axle, 60 mm travel
Drivetrain
Shift Levers
Enviolo Automatic Controller
Cassette
Gates CDX, 22 T, steel
Crank
ProWheel alloy, 175 mm length
Pedals
Bontrager City pedals
Wheels
Front Hub
Bontrager sealed bearing, 32-hole, 15 mm alloy thru-axle
Rear Hub
Enviolo Trekking, 32-hole, 6-bolt disc, 44T
Rims
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tires
Schwalbe Super Moto-X, reflective, wire bead, GreenGuard protection, 650x62 mm
Brakes
Brakes
Size: L, XL, XXL, Shimano MT401/MT410 hydraulic disc; Size: L, XL, XXL, Shimano MT401 / MT420 hydraulic disc
Cockpit
Stem
Alloy adjustable stem, 110 mm length
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Bontrager Satellite Elite, alloy lock-on
Seat
Saddle
Selle Royal ON relaxed
Seatpost
Ergotec PM705-N suspension
Motor & Battery
Motor
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Remote
Bosch Kiox 500, smart system
Charger
Bosch standard 4A, 230V, smart system
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 55cm | 60cm | 65cm |
|---|---|---|---|
| Stack Reach Ratio | 1.758 mm | 1.782 mm | 1.759 mm |
| Bottom Bracket Height | 294 mm | 294 mm | 294 mm |
| Front Center | 673 mm | 685 mm | 690 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 95 mm | 95 mm | 95 mm |
| Stack | 668 mm | 686 mm | 686 mm |
| Reach | 380 mm | 385 mm | 390 mm |
| Top Tube Length | 610 mm | 621 mm | 626 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 550 mm | 600 mm | 650 |
| Head Tube Angle | 68.2 ° | 68.2 ° | 68.2 ° |
| Head Tube Length | 200 mm | 220 mm | 220 mm |
| Chainstay Length | 487 mm | 487 mm | 487 mm |
| Wheelbase | 1152 mm | 1165 mm | 1170 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 853 mm | 887 mm | 911 mm |
| Wheels | 700 | 700 | 700 |
