Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
45cm
155cm - 166cm
50cm
164cm - 176cm
55cm
174cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR
Suspension Fork
FX alloy, flat-mount disc, rack mounts, 410 mm axle-to-crown, ThruSkew 5 mm QR
Drivetrain
Rear Derailleur
Shimano CUES U4000
Shift Levers
Shimano U4000, 9-speed
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Crank
ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length
Bottom Bracket
Sealed cartridge, 68 mm
Chain
Shimano LG500
Pedals
Bontrager City pedals
Wheels
Tires
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
Brakes
Brakes
Tektro HD-R280 hydraulic disc, 160 mm rotor
Cockpit
Stem
Size: S, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length; Size: M, L, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Handlebar
Size: S, M, Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width; Size: L, Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips
Bontrager Satellite
Seat
Saddle
Bontrager Sport Women's
Seatpost
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm |
|---|---|---|---|
| Stack Reach Ratio | 1.475 mm | 1.511 mm | 1.554 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm |
| Front Center | 620 mm | 631 mm | 641 mm |
| Rake | 51 mm | 50 mm | 50 mm |
| Trail | 71 mm | 68 mm | 64 mm |
| Stack | 568 mm | 594 mm | 620 mm |
| Reach | 385 mm | 393 mm | 399 mm |
| Top Tube Length | 543 mm | 563 mm | 583 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 375 mm | 420 mm | 465 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 140 mm | 165 mm | 190 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1059 mm | 1070 mm | 1080 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 623 mm | 622 mm | 624 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm |
