Trek FX+ 2 LT 2025
2025 E-bike
Estimate price |
2,675$
Weight | 17.75 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Acera -
Suspension Rigid -
Motor 250W 40Nm hub-drive -
Battery 250 Wh, integrated in down tube -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
45cm
155cm - 166cm
50cm
164cm - 176cm
55cm
174cm - 187cm
60cm
185cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminium, internal cable routing, internal battery, rack and mudguard mounts, kickstand mount
Suspension Fork
Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR
Drivetrain
Rear Derailleur
Shimano Acera M3020-8, 40T max cog
Shift Levers
Shimano M315, 8-speed
Cassette
Shimano HG400, 11-40, 8-speed
Crank
Size: S, M, ProWheel Pro alloy, 42T narrow-wide steel ring, 170 mm length; Size: L, XL, ProWheel Pro alloy, 42T narrow-wide steel ring, 175 mm length
Bottom Bracket
Torque sensor, threaded, 122.5 mm spindle
Chain
KMC Z8.3
Pedals
slip-proof pedals with reflectors
Wheels
Front Hub
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Rear Hub
Hyena hub drive motor, 40 Nm, 250 W
Rims
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tires
Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700x40 mm
Brakes
Brakes
Shimano hydraulic disc, MT200 lever, UR300 calliper
Cockpit
Stem
Size: S, M, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length; Size: L, XL, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Handlebar
Size: S, M, Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width; Size: L, XL, Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Seat
Saddle
Bontrager Sport
Seatpost
Size: S, M, Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length; Size: L, XL, Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Motor & Battery
Motor
Hyena hub drive motor, 40 Nm, 250 W
Battery
250 Wh, integrated in down tube
Charger
2A, 42V output, 100V–240V AC input
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.581 mm | 1.61 mm | 1.654 mm | 1.651 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 633 mm | 636 mm | 650 | 664 mm |
| Rake | 50 mm | 49 mm | 51 mm | 49 mm |
| Trail | 76 mm | 73 mm | 69 mm | 66 mm |
| Stack | 604 mm | 620 mm | 650 | 672 mm |
| Reach | 382 mm | 385 mm | 393 mm | 407 mm |
| Top Tube Length | 569 mm | 574 mm | 592 mm | 612 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 408 mm | 463 mm | 507 mm | 558 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 155 mm | 170 mm | 200 mm | 220 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1092 mm | 1095 mm | 1109 mm | 1123 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 739 mm | 780 mm | 820 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 185 cm |
| Rider Max Height | 166 cm | 176 cm | 187 cm | 197 cm |
