Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork RockShox
-
Groupset SX Eagle, Shimano -
Suspension Hardtail -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Platinum Series 6066 butted & hydroformed aluminum, cold-forged dropouts, G2 29" Geometry
Suspension Fork
RockShox Dart 3 29", 80mm travel, 46mm offset crown, coil spring, turnkey lockout w/external rebound adjustment
Drivetrain
Rear Derailleur
SRAM SX 4
Front Derailleur
Shimano M412
Shift Levers
SRAM SX 4, trigger
Cassette
SRAM PG830 11-32T, 8spd
Pedals
Wellgo ATB, boron axle, steel cage
Wheels
Rims
Shimano M65 hubs, Bontrager Ranger disc 29" rims, 32h
Tires
Bontrager XDX, 29x2.1 (53/51), tubeless ready, abrasion resistant,120 TPI aramid folding bead
Brakes
Brakes
Shimano M415, mechanical disc, 160mm 6-bolt rotors
Cockpit
Stem
Bontrager SSR, 10d rise
Handlebar
Bontrager Big Sweep, 600mm width, 15d backsweep
Headset
1-1/8" threadless, semi-integrated, semi-cartridge bearings
Seat
Saddle
Bontrager Race
Seatpost
Bontrager SSR, micro adjust, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Mamba is part of the Trek Mamba model. Trek released 9 bikes variations of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Mamba components
Fork
The Mamba comes factory-installed with the RockShox fork. This has a travel range of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Mamba model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Mamba comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Trek Mamba bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
