Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork Fox
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Platinum Series 6066 butted and hydroformed aluminum w/eccentric bottom bracket, G2 29" Geometry
Suspension Fork
Fox F80 RL 29 w/air pressure, rebound, lockout, alloy steerer, 80mm travel, G2 offset
Drivetrain
Cassette
Single cog, 18t
Crank
Bontrager Race Lite Singlespeed, 32T
Bottom Bracket
EBB, press-fit
Wheels
Rims
Bontrager Race Singlespeed hubs, Bontrager Duster 29" rims(tubeless ready rim strips, valves and sealant sold separately)
Tires
Bontrager Jones ACX, 29x2.2, folding, tubeless ready
Brakes
Brakes
Avid BB7 mechanical disc w/Avid SD 7 levers
Cockpit
Stem
Bontrager Select, 31.8mm, 7 degree
Handlebar
Bontrager Select Big Sweep, 31.8mm, 12d
Headset
Aheadset semi-integrated w/semi-cartridge bearings, sealed
Seat
Saddle
Bontrager Race Lite
Seatpost
Bontrager Sport
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rig belongs to the Trek Rig model. There are 10 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
This bike has the Fox fork installed. The fork’s travel is 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on Rig are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek Rig is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Rig comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
