Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork Fox
-
Groupset X7, X9 -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Platinum Series 6066 butted & hydroformed aluminum, cold-forged dropouts, G2 29" Geometry
Suspension Fork
Fox F80RL 29, 80mm travel, custom G2 Geometry 51mm offset crown, air spring, external rebound & lockout
Drivetrain
Rear Derailleur
SRAM X.7
Front Derailleur
SRAM X.9
Shift Levers
SRAM X.7, trigger
Cassette
SRAM PG950 11-32T, 9spd
Wheels
Rims
Bontrager Rhythm Disc 29, 28mm wide tubeless ready* rims
Tires
Bontrager XDX, 29x2.1 (53/51), tubeless ready, abrasion resistant,120 TPI aramid folding bead
Brakes
Brakes
Avid Juicy 3, hydraulic disc, 160mm Roundagon 6-bolt rotors
Cockpit
Stem
Bontrager SSR, 10d rise, 31.8mm
Handlebar
Bontrager Race Big Sweep, 620mm width, 12d backsweep, 31.8mm
Headset
1-1/8" threadless, semi-integrated, semi-cartridge bearings
Seat
Saddle
Bontrager Race
Seatpost
Bontrager SSR, micro adjust, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
X-Caliber completes the Trek X Caliber model. There are 60 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
X-Caliber components
Fork
This bike has the Fox fork installed. The fork’s travel is 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on X-Caliber are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek X-Caliber has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
X-Caliber comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
