Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Rear 89mm -
Groupset GRX 800 -
Suspension Full -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 TFW, bottom bracket: press-fit 89 mm, hub mount: thru axle 12x142 mm, tire clearance: 35 mm with plates/40 mm without, cable routing: partially integrated, brake: flat mount, mudguard and luggage rack eyelets, derailleur mounting: clamp
Suspension Fork
Aluminium TDE 3.5, axle mount: 12x100 mm thru axle, steerer tube: 1 1/8" to 1.5", disc brake mount: flat mount, lowrider eyelets, max. tire width: 37 mm with mudguards/40 mm without
Drivetrain
Rear Derailleur
Shimano GRX RD-RX820, Shadow RD Plus design for optimal chain guidance, smooth, precise and quiet shifting, adjustable chain stabilizer for different terrain, largest pinion max. 42 teeth
Front Derailleur
Shimano GRX FD-RX820, direct mount, lighter and smoother shifting, chainstay angle: 63-66°, chain line: 47 mm, largest chainring: 48 teeth, larger tire clearance
Shift Levers
Shimano GRX ST-RX820, dual control with servo wave brake function, gravel-optimized ergonomics for more control, especially for handlebars with flare, non-slip surfaces, grip width and pressure point settings
Cassette
Shimano CS-HG710-12, 12-speed HYPERGLIDE, gradation: 11-12-13-14-15-17-19-21-24-28-32-36
Crank
Shimano GRX RX-820-2, 48-31 teeth, crank length: 170 mm or 175 mm, depending on frame height, Q-factor: 151 mm, light and stiff HOLLOW TECH II design, large gear range
Chain
Shimano CN-M7100, 12-speed HYPERGLIDE+, SIL-TEC coating for longer durability
Pedals
TRENGA HPL Platform, non-slip tread for more safety, aluminum pedal body, reflectors
Wheels
Rims
Ryde Rival 19 Disc, lightweight all-round rim, ideal for trekking and touring, 32 holes, ETRTO: 19-622
Spokes
Sapim Race, Material: Stainless steel, Diameter: 2.0 / 1.8 mm, Color: Black
Tires
Continental Contact Urban, ETRTO: 35-622, Easy-rolling and puncture-proof urban tire, Reflective strips, Hand-made, For special e-bike requirements
Brakes
Brakes
Shimano GRX 820 hydraulic disc brake, powerful and finely dosed thanks to servo wave design, grip width and pressure point settings, ICE technologies, brake lever: ST-RX820 Dual Control, brake calliper: BR-RX820 2-piston, brake pad: K05S-RX Resin
Cockpit
Stem
TRENGA aluminum rigid, length: depending on frame size, fork clamp Ø: 28.6 mm, handlebar clamp Ø: 31.8 mm, angle: ± 6°
Handlebar
TRENGA, width: 420 mm, handlebar clamp Ø: 31.8 mm, reach: 87.6 mm
Seat
Saddle
Selle Italia ST-5 Flow, combines comfort with sporty design, FLOW opening relieves the perineal area, gel padding with Soft-Tek cover, Hi-Viz inserts increase visibility in the dark
Seatpost
TRENGA aluminium rigid, diameter: 27.2 mm, length: 300 mm, clamping: 2-way, offset: 18 mm
