Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano BT-E8010 Lithium-ion 504Wh -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
XCM 34 15x110
Drivetrain
Rear Derailleur
Shimano RD-M5120 Deore 10
Front Derailleur
-
Crank
Shimano FC-E8000 34T 165mm
Pedals
VP-535
Wheels
Rims
Rodi Tryp 25 double-wall
Tires
Smart Sam perfomance (57-584) 27.5x2.25
Brakes
Brakes
Shimano MT-401/MT410 2-piston
Cockpit
Handlebar
JD Superfit alloy W:760mm BS:9 DIA:31.8mm
Seat
Seatpost
Al 31.6mm
Motor & Battery
Motor
Shimano E7000 60Nm
Battery
Shimano BT-E8010 Lithium-ion 504Wh
Remote
SC-E7000 1.39" (4cm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 27" | 27" |
