Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 60mm -
Fork RST VOLANT
-
Groupset Alivio -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano BT-E8035 504Wh 36V 14 Ah -
Brakes Shimano Alivio Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium, high-frame
Suspension Fork
RST Volant 9 TNL(HLO) 60mm
Drivetrain
Rear Derailleur
Shimano RD-M3100 9
Front Derailleur
-
Crank
Shimano FC-E6100 170MM
Pedals
SP-820
Wheels
Rims
X430, aluminium, double-wall 622-19C
Tires
Schwalbe Road Cruiser Plus (42-622), puncture protection, side reflector
Brakes
Brakes
Shimano MT-200 hydraulic disc brakes
Cockpit
Handlebar
XLC al 640mm
Seat
Seatpost
Al 30.9mm
Motor & Battery
Motor
Shimano E6100 60Nm
Battery
Shimano BT-E8035 504Wh 36V 14 Ah
Remote
SC-E6100 2.7" (6.9cm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 56cm |
|---|---|---|
| Wheels | 700 | 700 |
