Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork Suntour NEX -
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano BT-E8014 Lithium-ion 418Wh 36V 11,6 Ah -
Brakes Shimano Alivio Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Suntour NEX-E25 HLO
Drivetrain
Rear Derailleur
Shimano RD-M4120 10
Front Derailleur
-
Crank
Shimano FC-E6100 170mm
Pedals
SP-820
Wheels
Rims
Rodi Connect, aluminium double-wall 622x19C
Tires
Big Ben K-Guard (50-622), sivuheijastin
Brakes
Brakes
Shimano MT-200 hydraulic disc brakes
Cockpit
Handlebar
Aluminium 620mm
Seat
Seatpost
Aluminium 30,4mm
Motor & Battery
Motor
Shimano E6100 60Nm
Battery
Shimano BT-E8014 Lithium-ion 418Wh 36V 11,6 Ah
Remote
SC-E6100 2.7" (6.9cm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm |
|---|---|
| Wheels | 29" |
| Rider Min Height | 120 cm |
