Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Unno DASH; Carbon fibre monocoque with 140mm of rear travel. Virtual pivot suspension system. Integrated chain guide and seat tube clamp. Downtube protector. EnduroMAX Bearings. Internal cable routing. Boost thru axle 12x148. Post Mount brake system. Max tire width: 2.6”. Oceanworks recycled plastic parts. Recycled rubber protectors. Recommended sag: 35% (+/- 5%).
Suspension Fork
Rockshox Lyrik Select; 150mm travel. DebonAir. Boost 15x110mm axle.
Rear Shock
Rockshox Superdeluxe Select; DebonAir. 230x57.5mm.
Drivetrain
Rear Derailleur
SRAM GX Eagle; 12 speed. Mechanical. X-Actuation. Colour: Lunar. Cage material: aluminum. Pulley bearings: steel.
Cassette
SRAM GX; XG 1275. 500% Range. 10-50. Finish: black. X-Glide 2.
Crank
SRAM GX Eagle; Alloy. Lunar. 12 speed.
Chain
SRAM GX; Eagle technology. 120 links. Solid pin.
Wheels
Rims
DT Swiss M1900 Spline; Diameter: 29". DT 370 hub. 30mm inner width.
Tires
Front: Continental Kryptotal-F Trail; 29x2.40. Trail endurance. Foldable skin SL. Black/Black., Rear: Continental Kryptotal-R Trail; 29x2.40. Trail endurance. Foldable skin SL. Black/Black.
Brakes
Brakes
Formula Cura 4; 4x18mm pistons on Caliper. SRAM Mixmaster. Sintered Pads. Axial Master Cylinder. Forged Aluminium. 850mm front hose and 2000mm rear hose.
Cockpit
Stem
E*Thirteen Base; Alloy. 35mm.
Handlebar
E*Thirteen Base; Alloy. 35mm.
Headset
Acros Internal Cable Routing; IS52. 1.5 / 1.5, with Acros spider with entry ports for cable routing.
Seat
Saddle
Selle Italia; SLR Boost.
Seatpost
OneUp V3; Mechanical. Travel: 120mm for S1, 150mm for S2 and 180mm for S3.
