Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset X0 Eagle Transmission -
Suspension Full -
Motor DJI 250W 70Nm mid-drive -
Battery DJI Avinox 800Wh; Integrated 3.74kg battery, delivered with a fast charger, 0 to 100% in 2h 25min. -
Drivetrain 1 × 12 Electronic -
Brakes Formula Cura 4 Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MITH; Carbon fibre monocoque with 160mm of rear travel. Virtual pivot suspension system. Integrated display, battery, chain guide and seat tube clamp. Motor protector. EnduroMAX Bearings. Internal cable routing. Boost thru axle 12x148. Post Mount brake system. Max tire width: 2.6”. Recommended SAG: 30-35%.
Suspension Fork
Fox 38 Factory; 170mm travel. Kashima coating. Grip X2 damper. Adjustments: HSC, LSC, HSR, LSR. 44mm offset.
Rear Shock
Fox Float X2 Factory; 230x65mm. Kashima coating. 2-pos lever. VVC Rebound. Adjustments: HSC, LSC, HSR, LSR.
Drivetrain
Rear Derailleur
SRAM X0 Eagle AXS T-Type; 12 speed. AXS Wireless. T-type.
Cassette
SRAM X0 T-Type; XS- 1295. 12 speed. 10-52t
Crank
UNNO 36t;
Chain
SRAM X0 T-Type; 120 links. Flat top. 12 speed
Wheels
Rims
NEWMEN Phase 30 Carbon; Mullet 29" Front and 27.5" Rear.
Tires
Front: SCHWALBE Magic Mary; Ultra Soft, Gravity Pro, TLR, 29” x 2.5”, Rear: SCHWALBE Magic Mary; Soft Evo, Gravity Pro, TLR, 27.5” x 2.5”
Brakes
Brakes
Formula Cura 4; 4x18mm pistons on Caliper. SRAM Mixmaster. Sintered Pads. Axial Master Cylinder. Forged Aluminium. 850mm front hose and 2000mm rear hose.
Cockpit
Headset
ACROS Block-Lock; 135º w/ CANE CREEK spacers
Seat
Saddle
FIZIK Terra Aidon X5; 145mm
Seatpost
OneUp V3; Mechanical. Travel: 180mm, 31.6mm - 22.2mm
Motor & Battery
Motor
DJI Avinox; 2,52 Kg drive unit with 70Nm (Eco), 105Nm (Auto, Trail, Turbo) and 120Nm (Boost). Offers 250W (rated), 850W (peak) and 1000W (max.) of power.
Battery
DJI Avinox 800Wh; Integrated 3.74kg battery, delivered with a fast charger, 0 to 100% in 2h 25min.
Remote
SRAM AXS; Pod Discrete Clamp
