Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Acera, Shimano -
Suspension Rigid -
Motor 250W hub-drive -
Battery Watt Hours: 352.8 Wh, Details: Samsung 36 Volt, Lithium-ion, 9.8 Amp Hrs, 4.8 lbs, Weight: 5 lbs (2.26 kg) -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Alloy, Hydroformed
Suspension Fork
Rigid Aluminum Alloy Hydroformed, 100mm Hub Spacing, 9mm Axle with Quick Release Skewer
Drivetrain
Rear Derailleur
Shimano Acera Derailleur
Shift Levers
Shimano RevoShift Half-Grip Shifter with Optical Gear Window
Cassette
SunRace 11-32 Tooth Cassette
Crank
Prowheel Cold Forged Aluminum Alloy Crank Arms, 170mm Length
Pedals
Generic Plastic Platform with Rubber Tread
Wheels
Rims
28"
Spokes
Stainless Steel, 14 Gauge, Black with Nipples
Tires
CST, 700 x 40c, (42-622)
Brakes
Brakes
Tektro Hydraulic Disc with 160mm Rotors, Dual-Piston Calipers, Three-Finger Levers with Adjustable Reach
Cockpit
Stem
Aluminum Alloy, 40mm Base Height, 50mm Length, Integrated Into Handlebar, Custom Top Interface for Display Mount, 20mm Tapered Base Spacer
Handlebar
Aluminum Alloy, Swept Back, (Sample Had Bar Merged with Stem, Production Version May Be Adjustable), 670mm Length
Grips
Faux Leather, Flat, Inner Lock Ring
Headset
Sealed, Integrated Design, 1-1/8" Straight
Seat
Saddle
Urtopia Branded Cionlli
Seatpost
Promax, Aluminum Alloy, 25mm Offset, Single Bolt Clamp
Motor & Battery
Motor
Type: Hub, Output: 350, Details: AKM100SX 250W or 350W, Weight: 5 lbs (2.26 kg)
Battery
Watt Hours: 352.8 Wh, Details: Samsung 36 Volt, Lithium-ion, 9.8 Amp Hrs, 4.8 lbs, Weight: 5 lbs (2.26 kg)
Charger
1.8 lb 42 Volt 4 Amp Battery Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17.5" |
|---|---|
| Wheels | 700 |
| Rider Min Height | 120 cm |
Model Overview
Chord completes the Urtopia E Chord model. There is 1 e-bike that carries this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
General Urban e-bikes average price
If you want an acceptable General Urban e-bike you should know that the average price is 2098$. However, even if your budget is less than the average, you might still be able to get a top-quality General Urban e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
This e-bike was released in 2023 and its price was 1999$. Comparing the average cost of a General Urban e-bike to this one, you will see that Chord price is 4.95% smaller.
Chord components
Fork material
The fork on this e-bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
As for the wheels, Urtopia Chord 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Chord has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
