Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 110mm -
Fork Suntour DUROLUX
-
Groupset Gates -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Powertube 500 -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
149cm - 162cm
MD
160cm - 175cm
LG
172cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed Aluminum w/ NAILD suspension technology inside
Suspension Fork
SunTour Durolux36, 110mm Travel
Rear Shock
SunTour RS-Edge-R
Drivetrain
Shift Levers
Enviolo Twist Shifter
Cassette
Gates CDX 22T
Crank
Praxis Alloy E-Crank for gates
Chain
Gates Carbon
Wheels
Rims
Alex MD40, 32H
Spokes
Stainless
Tires
Schwable Super Moto-X 62-584 Reflex
Brakes
Brakes
Shimano M6120 4 piston
Cockpit
Stem
VAAST, Kiox integrated, 75mm
Handlebar
VAAST, 31.8mm Alloy, 640mm width, 34D sweep
Seat
Saddle
Selle Royal Forum w/ Gel
Seatpost
Integrated w/ Battery storage
Motor & Battery
Motor
Bosch Gen. 4 Performance Line Speed (US) | Bosch Gen. 4 Performance Line - CX (EU/UK)
Battery
Bosch Powertube 500
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.386 mm | 1.375 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 763 mm | 799 mm | 845 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm |
| Stack | 644 mm | 672 mm | 708 mm |
| Reach | 460 mm | 485 mm | 515 mm |
| Top Tube Length | 597 mm | 632 mm | 674 mm |
| Seat Tube Angle | 77.3 ° | 77.7 ° | 78 ° |
| Seat Tube Length | 513 mm | 513 mm | 513 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 130 mm | 160 mm | 200 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1212 mm | 1248 mm | 1294 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Standover Height | 493 mm | 493 mm | 493 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 149 cm | 160 cm | 172 cm |
| Rider Max Height | 162 cm | 175 cm | 193 cm |
