Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Wheels 29" -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XC - Trail 29" / 27.5" AE81 ALLITE® Super Mag™, VAAST XC / Trail geometry, internal cable routing, dropper post ready
Suspension Fork
RockShox 35 Gold RL, 120mm Travel, DebonAir, 51mm offset, 15x110mm BOOST™
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX, 12-speed
Cassette
Shimano 10-51T, 12-speed
Crank
Praxis Cadet M30, 32T
Bottom Bracket
Praxis T47 IB Enduro Bearings
Chain
KMC X12 Nickel plated
Wheels
Rims
Stans NoTubes Arch S1, 28H w/Stans tubeless rim tape
Spokes
Double butted stainless
Tires
Maxxis Recon 29 x 2.4"F / 2.25"R, EXO/Tubeless Ready
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano 180mm F / 160mm R
Cockpit
Stem
VAAST MTB Pro
Handlebar
VAAST MTB Pro, 15mm rise w/7 degree sweep, 780mm width
Seat
Saddle
WTB Silverado 142 Race
Seatpost
TranzX 30.9mm dropper post, (100mm S/M, 120mm L/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.48 mm | 1.43 mm | 1.4 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 664 mm | 690 mm | 715 mm | 741 mm |
| Rake | 39 mm | 39 mm | 40 mm | 40 mm |
| Trail | 109 mm | 109 mm | 108 mm | 108 mm |
| Stack | 613 mm | 618 mm | 627 mm | 641 mm |
| Reach | 393 mm | 418 mm | 438 mm | 458 mm |
| Top Tube Length | 575 mm | 600 mm | 624 mm | 648 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 415 mm | 450 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1090 mm | 1117 mm | 1142 mm | 1167 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 746 mm | 772 mm | 802 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
M/1 completes the Vaast M1 model. There are 5 bikes that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Vaast M/1 price was 2099$. In conclusion, this bike price is 31.59% smaller than the price of the average Trail bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
M/1 components
Fork
The M/1 comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the M/1 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The M/1 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Vaast M/1 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
