Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 163cm
SM
160cm - 170cm
MD
167cm - 177cm
LG
174cm - 184cm
XL
180cm - 189cm
XXL
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Road 700c disc, AE81 SuperMag, VAAST Road geometry, internal cable routing, fender ready. Up to 30mm tire clearance
Suspension Fork
VAAST Road full-carbon disc. Up to 30mm tire clearance
Drivetrain
Rear Derailleur
Shimano Ultegra R8000, 11-speed
Front Derailleur
Shimano Ultegra R8000, braze-on
Shift Levers
Shimano Ultegra Disc R8020
Cassette
Shimano Ultegra R8000, 11-speed, 11-30t
Crank
Praxis Zyante carbon 50/34t w/ M30 axle
Bottom Bracket
Praxis T47 IB Enduro Bearings
Chain
KMC X11 11-speed
Wheels
Rims
VAAST Aero 30mm Aluminum, Tubeless Ready
Spokes
Bladed Double butted stainless
Tires
Vittoria Rubino Pro, 700 x 25mm w/Ultralight tubes
Brakes
Brakes
Shimano Ultegra R8070, hydraulic disc
Cockpit
Stem
VAAST Aero Pro, 3D forged, 8 degree
Handlebar
VAAST Aero Carbon
Seat
Saddle
ProLogo Scratch M5 PAS w/T2.0 rails
Seatpost
VAAST Carbon fiber, (300mm 49/52, 350mm 54/56/58/60)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.378 mm | 1.421 mm | 1.456 mm | 1.475 mm | 1.477 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 272 mm | 272 mm | 275 mm | 275 mm |
| Front Center | 575 mm | 575 mm | 591 mm | 590 mm | 610 mm | 629 mm |
| Rake | 52 mm | 52 mm | 52 mm | 45 mm | 45 mm | 45 mm |
| Trail | 65 mm | 59 mm | 56 mm | 57 mm | 57 mm | 57 mm |
| Stack | 500 mm | 510 mm | 540 mm | 565 mm | 590 mm | 610 mm |
| Reach | 365 mm | 370 mm | 380 mm | 388 mm | 400 mm | 413 mm |
| Top Tube Length | 494 mm | 511 mm | 540 mm | 561 mm | 580 mm | 600 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 94 mm | 101 mm | 129 mm | 153 mm | 183 mm | 204 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 973 mm | 973 mm | 988 mm | 990 mm | 1009 mm | 1029 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 69 mm | 69 mm |
| Standover Height | 722 mm | 742 mm | 766 mm | 788 mm | 812 mm | 832 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 160 cm | 167 cm | 174 cm | 180 cm | 187 cm |
| Rider Max Height | 163 cm | 170 cm | 177 cm | 184 cm | 189 cm | 196 cm |
