Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Wheels 700c -
Groupset microSHIFT Advent -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Urban Optimized 700c / 650b AE81 ALLITE® Super Mag™, VAAST Urban geometry, internal cable routing, fender / rack ready
Suspension Fork
VAAST Urban full-carbon disc, rack & fender ready
Drivetrain
Rear Derailleur
microSHIFT Advent M619M 1 x 9 speed
Shift Levers
microSHIFT Advent 1 x 9
Cassette
microSHIFT 11-42T, 9-speed
Crank
Forged Alloy, 40T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC X9
Wheels
Rims
Alex 700c Double Wall aluminum, 28H, Presta Valve
Spokes
Double butted stainless
Tires
Schwable SPICER K-Guard, 700 x 35c w/ Reflective sidewalls
Brakes
Brakes
Hydraulic disc brakes w/Three finger lever
Disk Rotors
160mm F & R
Cockpit
Stem
VAAST 3D forged
Handlebar
VAAST Urban Pro, 6061 butted aluminum
Seat
Saddle
VAAST Urban Sport
Seatpost
VAAST Micro adjust aluminum, 27.2mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.45 mm |
| Front Center | 615 mm | 647 mm | 686 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 67 mm | 67 mm |
| Stack | 560 mm | 595 mm | 636 mm |
| Reach | 395 mm | 415 mm | 440 mm |
| Top Tube Length | 565 mm | 595 mm | 633 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 455 mm | 510 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 167 mm | 210 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1050 mm | 1082 mm | 1121 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 720 mm | 763 mm | 813 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
U/1 is part of the Vaast U1 model. 7 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1099$. If we compare this with the average Hybrid bike cost we notice that the price is 95.55% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
U/1 components
Fork material
U/1 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the U/1 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The U/1 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
